Industrial Type Gearboxes PH/PB Series

Industrial-type gearboxes are the gearboxes that provide service, especially under heavy working conditions, have a robust body, carry high moments up to 480000 Nm, and stand out with their silent operation and ease of maintenance.

Features of Industrial Type Gearboxes  PH/PB Series:

• They are helical-bevel gear reducers with a parallel axis or 90° axis angles at input and output.
• There are foot and flange connection options.
• The body has a rigid structure.
• They are reducers that can be used in high power needs and heavy conditions.
• System strength calculations are made in accordance with ISO, DIN, and NIEMANN standards.
• Different input options are available (IEC, W, ...).
• Different output options can be offered (Shaft output, Hollow spindle, Conical compression, ...).
• Different connection options are available (B5 flange, Torque arm platform, ...).
• The bodies can be spheroid (GGG 40-50) and gray (GG 20-25).
• Gears are manufactured from forged and 21NiCrMo2 case-hardened steel.
• High-quality bearings and sealing elements are used.
• Special requests of the customer can be met.
